Numeric Controls

The numerical control CN6 is a Industrial P.C. based, with Windows CE as operating system, made for positioning control and for the  automatisms connected to it, endowed with two Can Open lines with Master software DS402 profile for device connection. Developed for tool machine application on axles, controls the trajectory with a continuous loop that allows the changing of the speed of the motor as in high performances numerical controls designed for linear and circular interpolation.

• Typology: Can Open Numerical Control with management up to 8 axles, P.C. based
• Visualization: 5.7” TFT color VGA 640x480 pixels display
• Keyboard: polycarbonate, alphanumerical, customizable front panel
• Feeding: 24 V.c.c. 0.5 A
• Operating System: Real Time Windows CE 5.0 ®
• Mass storage: persistent static ram and flash memory
• External disk: pen flash USB
• Communication: two Can Open lines for driving and I/O modules, two RS232 serials (one configurable as RS485) for external P.C. connection, Bar Code reader or label printer, two USB 1.1, Ethernet, PS2 keyboard, PS2 mouse, Compact Flash, analogical OUT VGA
• Potentiometer: speed regulation from potentiometer connected to the external I/O module, enabled from parameter
• P.L.C.: internal 96 inputs + 96 outputs managing, with external remote I/O modules
• Standard software: axles motion in linear interpolation, electrical axle functionality, manual motion
